Equipped with a standard creasing roller that automatically creases paper prior to folding, preventing creases from cracking when processing thick stock.
Features a dual-fold plate design that supports a variety of basic folding patterns and accommodates paper weights ranging from 50 to 120 gsm.
Includes an automatic counting function, eliminating the need for manual counting during batch production.
Boasts a stable structure and user-friendly operation, making it ideal for processing promotional flyers and leaflets that require creasing.
This A3 two-plate folder is designed for large-format folding tasks, handling paper sizes up to A3 (max 300×630mm) with ease. Supporting basic folds like half fold and accordion fold at 120 sheets per minute, it delivers efficient performance. The large-capacity tray holds up to 500 sheets to minimize frequent refills, and automatic ascending/descending counters simplify batch management. With stable paper feeding and durable construction, it is ideal for copy shops and printers handling large-format flyers and manuals.
Model：
Paper size：
Paper type：
Table capacity：
Speed：
Plates quantity：
Counter：
Attachment：
Dimension：
Power Supply：
Weight：
Folding type：
A3
max 300mm×630mm；min 68mm×128mm
50gsm-180gsm
500 sheets
30-200pcs/minute
2
4 digit ascending / 3 digit descending counter
A group of line press rollers
1200mm×480mm×520mm
220V 50Hz 0.35A 130W
38Kg
Basic fold types available
A4
max 220mm×360mm；min 50mm×50mm
50gsm-120gsm
300 sheets
120pcs/minute
2
4 digit ascending / 3 digit descending counter
A group of line press rollers
910mm×360mm×425mm
220V 50Hz 0.35A 50W
18Kg
Basic fold types available
